3. FIRST POWER-ON, CONTROL SYSTEM, AND INITIAL CHECK

Do not turn the amplifier on for at least 2 hours after unpacking it in the room where it
will be used. Pay particular attention when you move it from a very cold into a warm
place - condensation is likely and this could result in damage to the high voltage circuits.
In such a case, wait at least 4 hours. A similar effect can occur after a rapid warming of
the operating room (for instance after switching on a powerful heater in a cold shack).
To avoid any damage (not covered by the warranty), never connect, or disconnect cables
while power is applied at either end of the cable.
Hot-plugging is technically incorrect and is a bad practice to connect or disconnect any
piece of equipment while it is powered on. Make sure the device is switched off before
connecting or disconnecting any cable.
After following all instructions in Section
(marked ON/OFF) is turned OFF (see
mains plug into the wall outlet prepared for it. The amplifier remains switched off.
d)
c)
Page 30 of 92 | S e c t i o n FIRST POWER-ON, CONTROL SYSTEM, AND INITIAL CHECK
