STEP 2 – Amplifier Settings
When the amplifier is turned on, push the POWER button to turn off the amplifier (back to
•
Low Energy standby mode);
Switch off the amplifier via Main Power
•
Connections
Pull the amplifier's line (mains) plug out of the outlet;
•
Do not disconnect GND connection;
•
Disconnect all cables (except GND connection) from the rear panel of the amplifier –
•
transceiver, antennas, etc.
Remove the GND connection last (see
wait 30 minutes for safety.
Connect the amplifier to the PC via RS-232 interface on the rear panel of the amplifier (see
•
Figure 7-8 | Rear panel – RS-232 port
- If your PC has a built-in RS-232 port, you have to use an RS-232 cable (see
RS-232 connection cable wiring
- If your computer does not have a built-in serial RS-232 interface use an "USB to RS-
232" converter (see
Check whether the rear panel mains rocker switch (marked ON/OFF) is turned off (must be).
•
Insert amplifier's mains plug into the wall outlet;
April 2024
, Pos. 1); Make sure the Main Power
Figure 7-8 | Rear panel – RS-232 port
Figure 7-8 | Rear panel – RS-232 port
Figure 7-2 | Examples of "USB to RS-232" converters
Rocker Switch (see
Rocker Switch is in OFF position;
DANGER
Figure 2-4 | Rear panel - Connections
).
) to connect an amplifier to the PC.
S e c t i o n MAINTENANCE | Page 67 of 92
Figure 2-4 | Rear panel -
, Pos. (a)) and
Table 7-2 |
).
