2. INSTALLATION

2.1. Unpacking and Initial Inspection

Before you install your amplifier, thoroughly read this manual.
First, carefully inspect the cardboard carton and its contents for physical damage.
ACOM ships amplifiers in highly protected containers, but it cannot assure that
mistreatment by shippers will not occur. If damage is evident, notify your dealer
immediately. Delay may void the carrier's warranty.
The packaged weight is about 16 kg and is recommended to be handled by two persons.
Keep all packing materials for possible future amplifier shipment (see Section
).
Provider
Unpack the amplifier as described below:
Open the cardboard carton (see
•
Figure 2-2 | ACOM 700S packaged in a cardboard box
Take out the top secure element
•
(see
Figure 2-2 | ACOM 700S packaged in a cardboard box
Open the internal cardboard carton
•
(see
Figure 2-2 | ACOM 700S packaged in a cardboard box
April 2024
CAUTION

Figure 2-1 | Packaging carton (outside view)
