5.2. Menu AMP SERVICE (Amplifier Service Functions)

The amplifier service menu (see
screen (see
Figure 5-1 | MENU SELECTION
The AMP SERVICE menu is used for checking and adjustment of the zero-signal (idle)
drain current of the final transistors and for testing some functions and circuits of the
amplifier when serviced. We recommend these procedures are carried out only by a
trained service technician!
The necessary service function is selected with the buttons
With the SELECT and SELECT
The inactive functions are greyed out and the active are red. When leaving a function submenu, it is turned
off and deactivated automatically. At pressing the EXIT button all service functions are turned off, and the
MENU SELECTION screen comes back (see
button, the basic screen returns (see
Page 48 of 92 | S e c t i o n MENUS - SETTINGS AND OPTIONS

Figure 5-3 | Menu AMP SERVICE

) at RX mode only.
NOTICE
buttons (left or right arrows) the selected function is turned ON or OFF.
Figure 5-1 | MENU SELECTION
Figure 3-2 | Basic screen
Figure 5-3 | Menu AMP SERVICE
Figure 5-3 | Menu AMP SERVICE
