Figure 4-3 | Amplifier Screen With Acom 04At Or 06At Antenna Tuner Installed - Acom 700S User Manual

The connection of ACOM 04AT or 06AT tuner will make accessible specific features on the amplifier display
that provide a transparent operation by following frequency and antenna selection changes in less than
50 ms.

Figure 4-3 | Amplifier screen with ACOM 04AT or 06AT antenna tuner installed

Figure 4-3 | Amplifier screen with ACOM 04AT or 06AT antenna tuner installed
The operation of ACOM S-series amplifiers (solid-state devices) with ACOM 04AT and
06AT are described in detail in the respective User's Manual:
• ACOM 04AT User's Manual;
• ACOM 06AT User's Manual.
The documentation is available for download at
Pay particular attention to Sections
Assignment and Unassignment
06AT control from amplifier front panel.
The use of non-ACOM antenna tuners is not recommended.
ACOM, as an Original Equipment Manufacturer, keeps the right to refuse the guarantee
claims if the non-ACOM tuner is used.
