2. INSTALLATION

Unpacking and Initial Inspection

2.1.
Before you install your amplifier, thoroughly read this manual.
First, carefully inspect the cardboard carton and its contents for physical damage.
ACOM ships amplifiers in highly protected containers, but it cannot assure that
mistreatment by shippers will not occur. If damage is evident, notify your dealer
immediately. Delay may void the carrier's warranty.
Keep all packing materials for possible future amplifier shipment (see Section
).
Provider

Line Voltage Selection

2.2.
The ACOM 1200S amplifier is supplied with built-in switching-mode power supply (SMPS).
The amplifier operates in an extended mains voltage range of 100-240 VAC (output power reduced to
about 500 W PEP below 200 VAC), with no internal switch over. The consumed current is purely sinusoidal,
Power Factor Corrected (PFC) and inrush limited. This makes the operation from unstable mains and
generators easy and trouble free.
Thanks to the built-in SMPS, the ACOM 1200S has no mains line voltage selector to take
care of!
