Specifications

GENERAL
Supply voltage
Operating temperature 10°C to 40°C
Storage temperature
Humidity
MECHANICAL
Size
Weight
Cable length
OPERATION
Communication inter-
face to BlueBox
Debug signal valid in-
put voltage range
Power consumption
Number of supported
AGBT lanes
Maximum AGBT bitrate 5Gbps
AGBT clock source op-
tions
PROTECTION
Debug signals
DAP1-3 and DAPE1-3
DAP_RESET
VREF
9.0V DC via FNet cable
-10°C to 60°C
5% to 80% RH
80 x 55 x 18 mm
0.125 kg
31 cm
FNet
5.0V (max. 5.5V)
Max. 1.5W (dependent on operation mode)
1 lane
Active Probe
33 Ohm series termination/protection resistors, ESD protection devices
10k Ohm pull-down
1k Ohm pull-up, 33 series termination/protection resistor
1k Ohm input impedance
