Specifications

GENERAL
Operating temperature 10°C to 40°C
Storage temperature
Humidity
MECHANICAL
Size
Weight
OPERATION
Communication inter-
faces to PC
Supply voltage
Power consumption
ELECTRICAL
Debug signal valid in-
put voltage range
Debug signals
All inputs except the
TDO
TDO input
TMS and TDI debug
signals
RESET
TAR_VREF (target refer-
ence voltage) pin
-10°C to 60°C
5% to 80% RH
122 x 127 x 45 mm (W x D x H)
approx. 500g
USB 2.0, 10/100 Mbps Ethernet
10V to 24V DC
< 8W
1.8V to 5.5V DC
47 series termination/protection resistors, ESD protection devices.
Depending on the specific debug adapter, termination might be differ-
ent from 47 on some critical signals.
10 kOhm pull-up resistor
10 kOhm pull-down resistor
10 kOhm pull-up resistor
1 kOhm pull-up resistor, buffer-driven to prevent current flow into an
unpowered iC5000 from a powered target board
100 kOhm input impedance
