TASKING INFINEON SGBT Hardware User Manual page 10

The following pinout is valid on the converter side:
Signal Dir-
Signal Description
ection
Ground
I AGBT TX0_P
I AGBT TX0_N
Not Connected
I/O Target Reset Pin
I/O Optional 2nd DAP data
I/O Optional 3rd DAP data
O DAP Clock
Not Connected
Not Connected
Not Connected
Ground
Blue colored signals are trace signals.
The following pinout is valid on the target side:
Signal Descrip-
Signal Direction
tion
I AGBT TX0_P
I AGBT TX0_N
Ground
Not Connected
Not Connected
Ground
Not Connected
Not Connected
Ground
Not Connected
Not Connected
Blue colored signals are trace signals.
*Current TriCore devices feature only one AGBT line while the Active Probe hardware is ready for fu-
ture devices with more AGBT lines.
Signal Pin
GND A1
TX0+ A2
TX0- A3
NC A4
nRESET A5
DAP2 A6
DAP3 A7
DAP0 A8
NC A9
NC A10
NC A11
GND A12
(HSTCU) USB-C pinout
Signal Pin
TX0+ 1
TX0- 3
GND 5
NC 7
NC 9
GND 11
NC 13
NC 15
GND 17
NC 19
NC 21
Revision A2: Samtec 22-pin ERF8 pinout
Pin Signal
B12 NC
B11 CLK+
B10 CLK-
B9 NC
B8 DAP1
B7 nTRST
B6 NC
B5 Vref
B4 NC
B3 NC
B2 NC
B1 GND
Pin Signal
2 Vref
4 DAP0
6 DAP1
8 NC
10 DAP2
12 nTRST/DAPEN
14 CLK+
16 CLK-
18 TGO
20 NC
22 nRESET
Signal Dir-
Signal Description
Not Connected
AGBT Clock
AGBT Clock
Not Connected
DAP Data
Output
Not Connected
Reference Voltage
Not Connected
Not Connected
Not Connected
Ground
Signal Descrip-
Signal Direction
tion
Reference
Voltage
DAP Clock
DAP Data
Not Connected
Optional 2nd
DAP data
Output
AGBT Clock
AGBT Clock
AGBT Trigger
out
Not Connected
Reset
www.tasking.com
ection
O
O
I
O
I
I
O
IO
I
O
O
O
I
IO
