TASKING INFINEON SGBT Hardware User Manual page 12

The following pinout is valid on the target side:
Signal Dir- Signal Description
ection
I Reference Voltage
Ground
Ground
Not Connected
Ground
Signal Direction is described from the BlueBox perspective.
When initially connecting the BlueBox to a target, ensure the debug adapter pinout
matches the Target connector to avoid potential hardware failure.
Signal Pin Pin
Vref 1 2
GND 3 4
GND 5 6
NC 7 8
GND 9 10
10-pin Infineon DAP pinout
Signal Signal Description
DAP1 DAP Data pin
DAP0 DAP clock
DAP2 Optional 2nd DAP Data pin
DAP3 Optional 3rd DAP Data pin
nRESET Reset
www.tasking.com
Signal Dir-
ection
I/O
O
I/O
I/O
I/O
