Specifications

GENERAL
Operating temperature 10°C to 40°C
Storage temperature
Humidity
MECHANICAL
Size
Weight
OPERATION
Communication inter-
faces to PC
Supply voltage
Power consumption
ELECTRICAL
Debug signal valid in-
put voltage range
Debug signals
All inputs except the
TDO
TDO input
TMS and TDI debug
signals
RESET
TAR_VREF (target ref-
erence voltage) pin
-10°C to 60°C
5% to 80% RH
155 x 155 x 65 mm
approx. 800g
USB 2.0, USB 3.0, 10/100 Ethernet
10V to 24V DC
< 15W
1.8V to 5.5V DC
47 Ohm series termination/protection resistors, ESD protection
devices, 100mA resettable fuses
10 kOhm pull-up resistor
10 kOhm pull-down resistor
10 kOhm pull-up resistor
1k Ohm pull-up resistor, buffer-driven to prevent current flow into an
unpowered iC5700 from a powered target board
100 kOhm input impedance
