Specifications

GENERAL
Supply voltage
Operating temperature 10°C to 40°C
Storage temperature
Humidity
MECHANICAL
Size
Weight
Cable length
OPERATION
Communication
interface to BlueBox
Debug signal valid
input voltage range
Power consumption
TARGET SIGNALS
Debug signals
DAP1-3 and DAPE1-3
DAP_RESET
5 mA via VREF needed for hot-attach functionality.
9.0V DC via FNet cable
-10°C to 60°C
5% to 80% RH
95 x 55 x 20 mm
0.155 kg
10 cm
iSYSTEM proprietary FNet
5.0V (max. 5.5V)
Max. 2.5 W (dependent on operation mode)
33 Ohm series termination/protection resistors
10k Ohm pull-down
1k Ohm pull-up
