Specifications

GENERAL
Operating temperature 10°C to 40°C
Storage temperature
Humidity
MECHANICAL
Size
Weight
ELECTRICAL
Supply voltage
Digital I/Os
DAP_RESET
I/O group D0, D1
I/O group D2, D3
Input sampling rate
Input edge detection
Analog I/Os
AOUT0, AOUT1
AIN0, AIN1
Power Sense
-10°C to 60°C
5% to 80% RH
100 x 125 x 55 mm
ca. 440 g
Powered through the FNet
2 x NXP TJA1027 (galvanic isolation)
·
2 x 8 channels configurable Input or Output operation
·
47Ohm serial termination + 47kOhm pull-down
·
Sampling rate 100MHz
·
Supported operating voltage: 1.66V – 3.6V
·
Voltage threshold: CMOS for operating voltage below 2V and LVTTL
for operating voltage 2V or higher
Refer to Texas Instruments SN74AVC8T245 datasheet for more details
on the VIL, VIH characteristics.
·
2 x 8 channels configurable Input or Output operation
·
47Ohm serial termination +
·
Sampling rate 20MHz
·
Supported operating voltage: 1.66V – 5.4V
·
Voltage threshold: CMOS for operating voltage below 2V and above
4.5V, in between can be considered LVTTL.
Refer to Texas Instruments SN74LVC8T245 datasheet for more details
on the VIL, VIH characteristics.
All 32 inputs are sampled on any input edge detection and every 8ms
when no edge is detected within 8ms time window.
Edge detection: Short non-periodic changes at min. 16ns width or peri-
odic signal up to 1MHz frequency.
Two analog outputs, 12-bit resolution, output range ±5V, settling time
250ns
Output drive capability 35mA and 30pF load.
Protection: 33Ohm serial termination
Two analog inputs, input impedance 530kOhm / 8pF, 12-bit resolution,
input range ±5V, max. sampling rate 12 MHz
10-pin IDC connector
Provision for target power consumption measurement via the optional
Power Probe (Ordering code IC50012).
pull-down
