Specifications - TASKING iSYSTEM ARM HSSTP II User Manual

Specifications

GENERAL
Supply voltage
Operating temperature
Storage temperature
Humidity
MECHANICAL
Size
Weight
OPERATION
Communication
interface to BlueBox
Debug signal valid
input voltage range
Power consumption
Number of supported
HSSTP lanes
Maximum HSSTP
bitrate
Supported event/trigger
signals
PROTECTION
Debug signals
Debug signals w/o
clock
RESET
VREF
9.0V DC via FNet cable
10°C to 40°C
-10°C to 60°C
5% to 80% RH
80 x 55 x 18 mm
0.125 kg
iSYSTEM proprietary FNet
3.3V (max. 3.6V)
Max. 2W (dependent on operation mode)
Up to 4
5Gbps
DGBREQ/DBGACK or TRIGIN/TRIGOUT
33 Ohm series termination/protection resistors, ESD protection devices
Configurable 4k7 pull-down / pull-up
1k Ohm pull-up
1k Ohm input impedance
