Specifications - TASKING iSYSTEM ARM HSSTP II Hardware User Manual

Specifications

GENERAL
Supply voltage
Operating temperature 10°C to 40°C
Storage temperature
Humidity
MECHANICAL
Size
Weight
Cable length
OPERATION
Communication inter-
face to BlueBox
Debug signal valid in-
put voltage range
Power consumption
Number of supported
HSSTP lanes
Maximum HSSTP
bitrate
Supported event/trig-
ger signals
PROTECTION
Debug signals
Debug signals w/o
clock
RESET
VREF
9.0V DC via FNet cable
-10°C to 60°C
5% to 80% RH
80 x 55 x 18 mm
0.125 kg
23 cm
iSYSTEM proprietary FNet
3.3V (max. 3.6V)
Max. 2W (dependent on operation mode)
Up to 4
5Gbps
DGBREQ/DBGACK or TRIGIN/TRIGOUT
33 Ohm series termination/protection resistors, ESD protection
devices
Configurable 4k7 pull-down / pull-up
1k Ohm pull-up
1k Ohm input impedance
