Chapter 2. API Reference
• The unit and the channel number this configuration refers to.
• GPIO numbers of the pulse input and the pulse gate input.
• Two pairs of parameters:
reacts depending on the the status of control signal and how counting is done positive / negative edge of the
pulses.
• Two limit values (minimum / maximum) that are used to establish watchpoints and trigger interrupts when the
pulse count is meeting particular limit.
Setting up of particular channel is then done by calling a function
pcnt_config_t as the input parameter.
To disable the pulse or the control input pin in configuration, provide PCNT_PIN_NOT_USED instead of the GPIO
number.
Operating the Counter
After doing setup with pcnt_unit_config(), the counter immediately starts to operate. The accumulated pulse
count can be checked by calling pcnt_get_counter_value().
There are couple of functions that allow to control the counter's operation: pcnt_counter_pause(),
pcnt_counter_resume()
It is also possible to dynamically change the previously set up counter modes with
calling pcnt_set_mode().
If desired, the pulse input pin and the control input pin may be changed "on the fly"using pcnt_set_pin().
To disable particular input provide as a function parameter PCNT_PIN_NOT_USED instead of the GPIO number.
Note: For the counter not to miss any pulses, the pulse duration should be longer than one APB_CLK cycle (12.5
ns). The pulses are sampled on the edges of the APB_CLK clock and may be missed, if fall between the edges. This
applies to counter operation with or without a filer.
Filtering Pulses
The PCNT unit features filters on each of the pulse and control inputs, adding the option to ignore short glitches in
the signals.
The length of ignored pulses is provided in APB_CLK clock cycles by calling pcnt_set_filter_value().
The current filter setting may be checked with pcnt_get_filter_value(). The APB_CLK clock is running
at 80 MHz.
The filter is put
pcnt_filter_disable().
Using Interrupts
There are five counter state watch events, defined in pcnt_evt_type_t, that are able to trigger an interrupt. The
event happens on the pulse counter reaching specific values:
• Minimum or maximum count values:
pcnt_config_t
• Threshold 0 or Threshold 1 values set using function pcnt_set_event_value().
• Pulse count = 0
To register, enable or disable an interrupt to service the above events, call pcnt_isr_register(),
pcnt_intr_enable(). and pcnt_intr_disable(). To enable or disable events on reaching threshold
values, you will also need to call functions
In order to check what are the threshold values currently set, use function pcnt_get_event_value().
Espressif Systems
pcnt_ctrl_mode_t
and pcnt_counter_clear()
into operation / suspended
as discussed in Configuration
pcnt_event_enable()
Submit Document Feedback
and pcnt_count_mode_t
pcnt_unit_config()
by calling
counter_l_lim or counter_h_lim provided in
and pcnt_event_disable().
330
to define how the counter
with above
pcnt_unit_config()
pcnt_filter_enable()
Release v4.4
by
/
