Power Supply Options
• USB-to-UART Port and ESP32-S2 USB Port (either one or both), default power supply (recommended)
• 5V and G (GND) pins
• 3V3 and G (GND) pins
Header Block The two tables below provide the Name and Function of the pin headers on both sides of the board
(J1 and J3). The pin header names are shown in
ESP32-S2-DevKitC-1 Schematic
1
No. Name Type
1 3V3 P
2 3V3 P
3 RST I
4 4 I/O/T
5 5 I/O/T
6 6 I/O/T
7 7 I/O/T
8 15 I/O/T
9 16 I/O/T
10 17 I/O/T
11 18 I/O/T
12 8 I/O/T
13 3 I/O/T
14 46 I
15 9 I/O/T
16 10 I/O/T
17 11 I/O/T
18 12 I/O/T
19 13 I/O/T
20 14 I/O/T
21 5V P
22 G G
P: Power supply; I: Input; O: Output; T: High impedance.
Espressif Systems
There are three mutually exclusive ways to provide power to the board:
ESP32-S2-DevKitC-1 -
(PDF).
Function
3.3 V power supply
3.3 V power supply
CHIP_PU
RTC_GPIO4, GPIO4, TOUCH4, ADC1_CH3
RTC_GPIO5, GPIO5, TOUCH5, ADC1_CH4
RTC_GPIO6, GPIO6, TOUCH6, ADC1_CH5
RTC_GPIO7, GPIO7, TOUCH7, ADC1_CH6
RTC_GPIO15, GPIO15, U0RTS, ADC2_CH4, XTAL_32K_P
RTC_GPIO16, GPIO16, U0CTS, ADC2_CH5, XTAL_32K_N
RTC_GPIO17, GPIO17, U1TXD, ADC2_CH6, DAC_1
RTC_GPIO18, GPIO18, U1RXD, ADC2_CH7, DAC_2, CLK_OUT3, RGB LED
RTC_GPIO8, GPIO8, TOUCH8, ADC1_CH7
RTC_GPIO3, GPIO3, TOUCH3, ADC1_CH2
GPIO46
RTC_GPIO9, GPIO9, TOUCH9, ADC1_CH8, FSPIHD
RTC_GPIO10, GPIO10, TOUCH10, ADC1_CH9, FSPICS0, FSPIIO4
RTC_GPIO11, GPIO11, TOUCH11, ADC2_CH0, FSPID, FSPIIO5
RTC_GPIO12, GPIO12, TOUCH12, ADC2_CH1, FSPICLK, FSPIIO6
RTC_GPIO13, GPIO13, TOUCH13, ADC2_CH2, FSPIQ, FSPIIO7
RTC_GPIO14, GPIO14, TOUCH14, ADC2_CH3, FSPIWP, FSPIDQS
5 V power supply
Ground
