Espressif ESP32-S2 Programming Manual page 140

Chapter 2. API Reference
Frame Format ESP-NOW uses a vendor-specific action frame to transmit ESP-NOW data. The default ESP-
NOW bit rate is 1 Mbps. The format of the vendor-specific action frame is as follows:
-----------------------------------------------------------------------------------
-------------------------
→
| MAC Header | Category Code | Organization Identifier | Random Values |
Specific Content |
→
-----------------------------------------------------------------------------------
-------------------------
→
24 bytes 1 byte
255 bytes 4 bytes
→
• Category Code: The Category Code field is set to the value(127) indicating the vendor-specific category.
• Organization Identifier: The Organization Identifier contains a unique identifier (0x18fe34), which is the first
three bytes of MAC address applied by Espressif.
• Random Value: The Random Value filed is used to prevents relay attacks.
• Vendor Specific Content: The Vendor Specific Content contains vendor-specific fields as follows:
-------------------------------------------------------------------------------
| Element ID | Length | Organization Identifier | Type | Version |
-------------------------------------------------------------------------------
1 byte 1 byte
• Element ID: The Element ID field is set to the value (221), indicating the vendor-specific element.
• Length: The length is the total length of Organization Identifier, Type, Version and Body.
• Organization Identifier: The Organization Identifier contains a unique identifier(0x18fe34), which is the first
three bytes of MAC address applied by Espressif.
• Type: The Type field is set to the value (4) indicating ESP-NOW.
• Version: The Version field is set to the version of ESP-NOW.
• Body: The Body contains the ESP-NOW data.
As ESP-NOW is connectionless, the MAC header is a little different from that of standard frames. The FromDS and
ToDS bits of FrameControl field are both 0. The first address field is set to the destination address. The second address
field is set to the source address. The third address field is set to broadcast address (0xff:0xff:0xff:0xff:0xff:0xff).
Security
ESP-NOW uses the CCMP method, which is described in IEEE Std. 802.11-2012, to protect the vendor-specific action frame
• PMK is used to encrypt LMK with the AES-128 algorithm. Call esp_now_set_pmk() to set PMK.
If PMK is not set, a default PMK will be used.
• LMK of the paired device is used to encrypt the vendor-specific action frame with the CCMP method.
The maximum number of different LMKs is six. If the LMK of the paired device is not set, the vendor-
specific action frame will not be encrypted.
Encrypting multicast vendor-specific action frame is not supported.
Initialization and De-initialization
esp_now_deinit() to de-initialize ESP-NOW. ESP-NOW data must be transmitted after Wi-Fi is started,
so it is recommended to start Wi-Fi before initializing ESP-NOW and stop Wi-Fi after de-initializing ESP-NOW.
When esp_now_deinit() is called, all of the information of paired devices will be deleted.
Add Paired Device Call esp_now_add_peer() to add the device to the paired device list before you send
data to this device. The maximum number of paired devices is twenty. If security is enabled, the LMK must be set.
You can send ESP-NOW data via both the Station and the SoftAP interface. Make sure that the interface is enabled
before sending ESP-NOW data. A device with a broadcast MAC address must be added before sending broadcast
data. The range of the channel of paired devices is from 0 to 14. If the channel is set to 0, data will be sent on the
current channel. Otherwise, the channel must be set as the channel that the local device is on.
Espressif Systems
FCS |
3 bytes
3 bytes
Call esp_now_init()
129
Submit Document Feedback
4 bytes
1 byte 1 byte 0~250 bytes
to initialize
Vendor␣
7~
Body |
ESP-NOW and
Release v4.4
