Chapter 1. Get Started
Key Component
Main Board Camera Header
Power ON LED
Camera Module Connector
Power Regulators
Start Application Development
condition with no obvious signs of damage.
Required Hardware
• Board with a female Camera Header (e.g., ESP32-S2-Kaluga-1)
• ESP-LyraP-CAM extension board
• Computer running Windows, Linux, or macOS
Hardware Setup
Insert the ESP-LyraP-CAM extension board into your board's female Camera Header.
Software Setup
See Section
Hardware Reference
Block Diagram
A block diagram below shows the components of the ESP-LyraP-CAM and their interconnections.
Hardware Revision Details
Espressif Systems
Fig. 37: ESP-LyraP-CAM - front and back
Description of Components
Description
Mount onto main board's Camera Header
Red LED is on if the power supply voltage is correct
Supports OV2640 and OV3660 camera modules; this extension board is sup-
plied with an OV2640 camera module
LDO Regulators converting 3.3 V to 2.8 V and 1.5 V
Before powering up your ESP-LyraP-CAM, please make sure that it is in good
Software Setup
of the ESP32-S2-Kaluga-1 kit user guide.
46
Submit Document Feedback
Release v4.4
