ESP-LyraT-8311A v1.2
This board cannot be bought separately and is usually sold together with other Espressif development boards (e.g.,
ESP32-S2-Kaluga-1), which will be referred to as main boards below.
Currently, ESP-LyraT-8311A v1.2 is sold as part of the
The ESP-LyraT-8311A extends the functionality of your main board by adding sound processing functionality:
• Audio playback/recording
• Processing of audio signals
• Programmable buttons for easy control
This extension board can be used in many ways. The applications might include voice user interface, voice control,
voice authorization, recording and playback of sound, etc.
The document consists of the following major sections:
• Overview: Provides an overview and hardware setup instructions.
•
Hardware
reference: Provides more detailed information about the ESP-LyraT-8311A's hardware.
•
Hardware Revision
Details: Covers revision history, known issues, and links to user guides for previous versions
of the ESP-LyraT-8311A.
•
Related
Documents: Gives links to related documentation.
Espressif Systems
(PDF)
(PDF)
This user guide provides information on the ESP-LyraT-8311A extension board.
Fig. 33: ESP-LyraT-8311A (click to enlarge)
