Description of the Upgrade
Installation Procedure for the Upgrade
Step 30. Enable Options 400
Procedure Requirements
For this step, you will need a USB flash drive.
— The analyzer must be powered up and operating to perform this procedure.
— The network analyzer program must not be running.
— A keyboard and mouse must be connected to the network analyzer.
Option Enable Procedure
1. Locate the email(s) from Keysight which contain license file attachments.
2. Copy the license file(s) from the email(s) to the root directory of the USB
A single license file may contain licenses for more than one instrument.
3. Insert the USB flash drive to the PNA's USB drive slot, within 5 seconds,
Attempting to re-install a license file that is already installed may generate
a "Corrupt Media" error message. Ignore this message.
4. Disconnect the USB flash drive from the PNA.
5. On the analyzer, click or press to open the KLM software from your PNA's
48
These emails are a result of
Information" on page
flash drive. More than one license file may be copied to the USB flash
drive.
the PNA should display a small "New licenses installed" message.
Else, load the license key file(s), manually move your license file(s) to
C:\Program Files\Agilent\licensing. It may take Keysight License
Manager an extra ~5 seconds to enable the licenses.
Windows taskbar by pressing Start > More Programs > Keysight License
Manager folder > Keysight License Manager and verify the options are
correct.
"Step 1. Obtain a Keyword and Verify the
14.
Installation Note N5225-90136
