Description of the Upgrade
Items Included in the Upgrade Kit
Table 1 Contents of Upgrade Kit N5225-60136
Ref
Desig.
W63 RF cable, A27 mixer brick (R2) to A24 IF multiplexer (P412)
W65 RF cable, A28 mixer brick (D) to A24 IF multiplexer (P801)
W66 RF cable, A28 mixer brick (R4) to A24 IF multiplexer (P414)
W67 RF cable, A28 mixer brick (R3) to A24 IF multiplexer (P413)
W68 RF cable, A28 mixer brick (C) to A24 IF multiplexer (P601)
W70 RF cable, A24 IF multiplexer board P203 to A16 SPAM board J2
W72 RF cable, A24 IF multiplexer board P603 to A16 SPAM board J5
W108 RF cable, A30 port 3 receiver coupler to A28 mixer brick (R3)
W109 RF cable, A31 port 4 receiver coupler to A28 mixer brick (R4)
W110 RF cable, A32 port 2 receiver coupler to A27 mixer brick (R2)
W111 RF cable, A29 port 1 receiver coupler to A33 port 1 coupler
W112 RF cable, A30 port 3 receiver coupler to A34 port 3 coupler
W113 RF cable, A31 port 4 receiver coupler to A35 port 4 coupler
W114 RF cable, A32 port 2 receiver coupler to A36 port 2 coupler
W115 RF cable, A33 port 1 coupler to A27 mixer brick (A)
W116 RF cable, A34 port 3 coupler to A28 mixer brick (C)
W117 RF cable, A35 port 4 coupler to A28 mixer brick (D)
W118 RF cable, A36 port 2 coupler to A27 mixer brick (B)
RF cable, A25 HMA26.5 (top) to A28 mixer brick (top)
b
W203
- Ribbon cable, A23 test set motherboard J552 to A28 mixer brick (2) J52
a. The A26 splitter (5067-4086) and N5245-20013, N5245-20022, N5245-20023, N545-20101, and N5245-20150 cables are
only used with a legacy HMA26.5 p/n: 5087-7765. If you are unclear which HMA26.5 assembly your PNA has installed, refer to
Chapter 7 Repairs and
6"2-Port Configurations, Serial Number Prefix <6021" and "4-Port Configuration, Serial Number Prefix <6021".
b. The N5245-20195 cable is used only with instruments that have a newer HMA26.5 installed. If your PNA has a legacy
5087-7765 HMA26.5 assembly installed, then this cable can be discarded. If you are unclear which HMA26.5 assembly your
PNA has installed, refer to
Extra quantities of items such as protective plastic caps, screws, cable ties,
and cable clamps may be included in this upgrade kit. It is normal for some
of these items to remain unused after the upgrade is completed.
14
Description
Figure 1 on page 7 and for details on A26 splitter and cabling, refer to your option-model in Chapter
Figure 1 on page 7.
Qty Part Number
1 N5242-60022
1 N5242-60024
1 N5242-60019
1 N5242-60020
1 N5242-60023
1 N5242-60013
1 N5242-60015
1 N5224-20024
1 N5224-20047
1 N5224-20028
1 N5224-20013
1 N5224-20015
1 N5224-20016
1 N5224-20014
1 N5224-20022
1 N5224-20023
1 N5224-20026
1 N5224-20025
1 N5245-20195
1 N5247-60015
Installation Note N5225-90136
