Description of the Upgrade
Installation Procedure for the Upgrade
3. Placing two fingers at the middle, press the overlay firmly onto the frame
4. Install the front panel jumpers.
Step 27. Position the Cables and Wires to Prevent Pinching
On the top side of the PNA, carefully position the gray flex cables so they can't
be pinched between the covers and the rails.
On the bottom side of the PNA, carefully fold or push down the ribbon cables
and wires so they can't be pinched between the hardware and the outer cover.
Ribbon cables and wires must never be positioned on top of hardware.
Step 28. Reinstall the Inner Cover
For instructions, click the Chapter 7 bookmark "Removing the Covers" in the
PDF Service Guide.
Step 29. Reinstall the Outer Cover
For instructions, click the Chapter 7 bookmark "Removing the Covers" in the
PDF Service Guide
Installation Note N5225-90136
while sliding your fingers in opposite directions towards the ends of the
overlay. Repeat on all areas of the overlay.
1
.
1. See "Downloading the Online PNA Service Guide" on page 8.
