Description of the Upgrade
Installation Procedure for the Upgrade
"Step 20. Install the Cable Bracket Mount."
"Step 21. Install the Test Set Cables."
"Step 22. Reinstall the A23 Test Set Motherboard."
"Step 23. Install Cable on the A23 Test Set Motherboard."
"Step 24. Replace the Front Panel's Lower Dress Panel."
"Step 25. Reinstall Front Panel Assembly."
"Step 26. Install the Overlay."
"Step 27. Position the Cables and Wires to Prevent Pinching."
"Step 28. Reinstall the Inner Cover."
"Step 29. Reinstall the Outer Cover."
"Step 30. Enable Options 400."
"Step 31. Perform Post-Upgrade Adjustments and Calibration."
"Step 32. Prepare the PNA for the User."
Step 1. Obtain a Keyword and Verify the Information
Follow the instructions on the Software Entitlement Certificate supplied to
obtain a license key for installation of this upgrade. Refer to
Redemption" on page
Verify that the model number, serial number, and option number information
on the license key match those of the instrument on which this upgrade will be
installed.s
Once the license key file has been received and the information verified, you
can proceed with the installation at step 2.
If the model number, serial number, or option number do not match those
on your license key file, you will not be able to install the option. If this is
the case, contact Keysight for assistance before beginning the installation
of this upgrade. Refer to
Step 2. Remove the Outer Cover
For instructions, click the Chapter 7 bookmark "Removing the Covers" in the
PDF Service Guide.
Step 3. Remove the Inner Cover
For instructions, click the Chapter 7 bookmark "Removing the Covers" in the
PDF Service Guide
16
6.
1
.
1. See "Downloading the Online PNA Service Guide" on page
"Contacting Keysight" on page
"License Key
4.
8.
Installation Note N5225-90136
