Description of the Upgrade
Getting Prepared
Tools Required for the Installation
Description
T-6 TORX driver - set to 4 in-lbs (0.45 N.m)
T-10 TORX driver - set to 9 in-lbs (1.02 N.m)
T-20 TORX driver - set to 21 in-lbs (2.38 N.m)
5/16-in (8 mm) nutsetter or open end torque wrench - set to 10 in-lbs
(1.13 N.m)
3/16-in (5 mm) nutsetter or open end torque wrench - set to 6 in-lbs
(0.68 N.m)
5/8-in (16 mm) nutsetter or open end torque wrench - set to 21 in-lbs
(2.38 N.m)
9 mm nutsetter or open end torque wrench - set to 21 in-lbs (2.38 N.m)
1-in (25.4 mm) torque wrench - set to 72 in-lbs (8.15 N.m)
Use a 5/16-in torque wrench set to 10 in-lbs on all cable connections
except the front and rear panel bulkhead connectors. On these, use a
9 mm nutsetter or open end torque wrench set to 21 in-lb.
About Installing the Upgrades
Products affected
Installation to be performed by
Estimated installation time
Estimated adjustment time
Estimated full instrument calibration time
Installation Note N5225-90136
N5224B and N5225B Option 200 with DDS installed
Keysight service center or personnel qualified by Keysight
5 hours
0.5 hours
4.5 hours
Qty Part Number
1
1
1
1
1
1
1
1
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
