Description of the Upgrade
Getting Prepared
Getting Prepared
The PNA contains extremely sensitive components that can be ruined if
mishandled. Follow instructions carefully when making cable connections,
especially wire harness connections.
The person performing the work accepts responsibility for the full cost of
the repair or replacement of damaged components.
IMPORTANT!
—
—
—
—
a. See "Downloading the Online PNA Service Guide" on page
To successfully install this upgrade kit, you will need the following:
— A license key - refer to
— A PDF copy or a paper copy of the PNA Service Guide - refer to
— An ESD-safe work area - refer to
— Correct tools - refer to
— Enough time - refer to
— Test equipment for the post-upgrade adjustments. To view the equipment
Installation Note N5225-90136
This document contains references to legacy and to new A25 HMA26.5
Multiplier/Amplifier and A27/A28 mixer brick assemblies. Your model
instrument may have some combination of legacy assemblies and new
parts installed. Both types of assemblies are compatible with this
upgrade. This note is for your reference, because some figures contain
legacy assemblies that your instrument may not have installed.
If you want to verify your instrument's A25 HMA26.5
Multiplier/Amplifier, refer to
Installed" on page 7.
Your A27/A28 mixer brick might be a legacy part number 5087-7323
(with (x2) discrete 3dB attenuators 08490-60039) or new part number
5087-7417 (with integrated 3 dB attenuators). The legacy A27/A28
mixer bricks and the new integrated mixer bricks, look the same, except
for the addition of the discrete A68/A69 attenuators on the legacy
mixer bricks.
See also, your instrument's PDF Service Guide
"Downloading the Online PNA Service Guide"
Electrostatic Discharge"
list, click the Chapter 3 bookmark "Tests and Adjustments" in the PDF
1
Service Guide .
1. See "Downloading the Online PNA Service Guide" on page
"Verify the Model/Version of HMA26.5
8.
"License Key Redemption"
"Protecting Your Workspace from
below.
"Tools Required for the Installation" on page
"About Installing the Upgrades" on page
a
.
below.
below.
9.
9.
8.
