- Page 1 Keysight PNA Series Network Analyzers INSTALLATION AND QUICK START GUIDE...
-
Page 2: Safety Notices
DOCUMENT OR ANY INFORMATION WARNING notice until the reproduce, release, perform, CONTAINED HEREIN. SHOULD indicated conditions are fully display, or disclose commercial KEYSIGHT AND THE USER HAVE A understood and met. SEPARATE WRITTEN AGREEMENT computer software or... -
Page 3: Where To Find The Latest Information
Information on preventing instrument damage can be found at: http://keysight.com/find/PreventingInstrumentRepair Is your product software up-to-date? Periodically, Keysight releases software updates to fix known defects and incorporate product enhancements. To search for software updates for your product, go to the Keysight Technical Support website at: http://www.keysight.com/find/techsupport... - Page 4 If you discover a cybersecurity issue that you suspect may involve Keysight's proprietary software, or third-party software supplied by Keysight as part of a product, or that may affect the operation of Keysight products, we encourage you to report it to us using this form: https://www.keysight.com/us/en/about/quality-and-security/security/product-and-solution-cyber-security/report-...
-
Page 5: Table Of Contents
“Models Covered in this Guide” on page 6 This section lists the model numbers covered in this guide. — “Getting Assistance from Keysight” on page 7 This section contains some general information and information on how to contact Keysight for support on your product. -
Page 6: Models Covered In This Guide
FedEx, UPS, etc. Shipping the PNA-X Pro requires that it be handled as freight, meaning that it must be secured to a pallet which can be lifted by a forklift. The PNA-X Pro is shipped from Keysight in this configuration. The end-user must retain this pallet and other shipping material for sending the PNA-X Pro to Keysight for its annual calibration or any servicing. -
Page 7: Getting Assistance From Keysight
Getting Assistance from Keysight Installing this upgrade kit requires special skills and experience. If you think you may not be qualified to do the work, or need advice, contact Keysight. Contacting Keysight For optimum service, before contacting Keysight, it is important to sign up for Keysight Care to improve turnaround time and committed service levels on both application support as well as post-sales support. -
Page 8: Safety Symbols
Procedures are provided for installing, configuring, and verifying the operation of the analyzer. Downloading PNA Documentation from the Web Documentation for all PNA models is available by going to: https://www.keysight.com/ entering your PNA model number, and clicking on Technical Support. Keysight PNA Installation and Quick Start Guide... -
Page 9: Operating Precautions
2. While wearing a grounded wrist strap, grasp the outer shell of the cable and DUT connector. 3. Connect the other end of the cable to the test port. 4. Remove the short from the cable. Keysight PNA Installation and Quick Start Guide... -
Page 10: Preventing Electrical Overstress Damage
In This Guide Operating Precautions Figure 0-1 ESD Protection Setup The following table lists Keysight part numbers for ESD protection devices. To order, refer to “Contacting Keysight” on page Description Keysight Part Number Grounding wrist strap 9300-1367 5-ft grounding cord for wrist strap... -
Page 11: Preventing Test Port Connector Damage
Proper connector care and connection techniques are critical for accurate and repeatable measurements. The following table contains for tips on connector care. For more information on the proper use and maintenance of connectors, see https://rfmw.em.keysight.com/wireless/helpfiles/N52xxB/Tutorials/Connect or_Care.htm. Keysight PNA Installation and Quick Start Guide... -
Page 12: Install Antivirus And Firewall Protection
— Do NOT change advanced performance settings or group policies. — Do NOT add or delete any SSD partitions on the PNA. — Do NOT delete the Keysight user account unless in a secured environment. — Do NOT modify any of the Keysight software registry entries. -
Page 13: Installing Your Analyzer
Safety of any system incorporating the equipment is the responsibility of the assembler of the system. Only Keysight approved accessories shall be used. This procedure requires an open or short calibration standard that mates with the front panel test ports. The open or short calibration standard is NOT included with the PNA. -
Page 14: Step 1. Check The Shipment
– Condensing humidity operating conditions are not allowed. Refer to “Environmental Information” on page – The instruments can operate with mains supply voltage fluctuations up to ± 10% of the nominal voltage. Keysight PNA Installation and Quick Start Guide... - Page 15 2. Verify that the AC power cable is not damaged, and that the power-source outlet provides a protective earth contact. Use Keysight supplied power cord or one with same or better electrical rating. Always use the three-prong AC power cord supplied with this product.
-
Page 16: Step 3. Install The Analyzer
(index entry) for more information. When starting the PNA, do not have any USB devices connected other than a mouse and keyboard. The current draw from other accessories can impact the initial boot-up sequence. Keysight PNA Installation and Quick Start Guide... - Page 17 The core should snap closed to grip the cable firmly, but without damaging the cable. Attach the core to the cable as close as possible to the PNA connector end. Cable ties help ensure that the ferrite cores remain in place Figure 3 Cable Keysight PNA Installation and Quick Start Guide...
-
Page 18: Step 6. Start Up The Analyzer
PNA. The only drawback comes with viewing the display from the bottom. The colors of some small display elements will appear to shift when the viewer’s eyes are more than 30 degrees Keysight PNA Installation and Quick Start Guide... -
Page 19: Step 7. Perform Administrative Tasks
— On the analyzer's front panel, press the Help button. Or, on the PNA display, click Help > Network Analyzer Help. Click Quick Start in PNA Help. Click Perform Administrative Tasks. Click the task you wish to perform. Keysight PNA Installation and Quick Start Guide... -
Page 20: Step 8. Run The Operator's Check
Shutdown mode. 2. If the PNA is locked and you cannot operate the mouse or keypad, turn OFF the PNA by pressing and holding the power button for at least four seconds. Keysight PNA Installation and Quick Start Guide... -
Page 21: Windows 10 Operating System
— Click Quick Start in PNA Help. PNA on the Internet Keysight maintains a large collection of resources for help with the PNA Family of Network Analyzers. You can find all PNA documentation and other resources by going to https://www.keysight.com/, entering your PNA model number, and clicking on Technical Support. -
Page 22: Safety, Regulatory, And Environmental Information
Use a dry cloth or one slightly dampened with water to clean the external case parts. Do not attempt to clean internally. Shipment for Service Contact Keysight Technologies for instructions on where to ship the analyzer for service. Refer to “Getting Assistance from Keysight” on page Ship the analyzer using the original or comparable packaging, impact covers, and antistatic materials. -
Page 23: General Safety Considerations
These devices may not be sufficiently rated to carry the required current and may become a safety hazard. DO NOT use extension cords to power your equipment. DO NOT use any converters or adapters. Keysight PNA Installation and Quick Start Guide... - Page 24 Do not obstruct openings. Allow a minimum 70 mm clearance for proper cooling. If there are any concerns or special requirements a Keysight Field Engineer should be consulted to assure instrument(s) temperature compliance and performance.
-
Page 25: Regulatory Information
The table below lists the definitions of markings that may be on or with the product. Familiarize yourself with each marking and its meaning before operating the instrument. Instructions for Use Keysight PNA Installation and Quick Start Guide... - Page 26 The instruction documentation symbol. The product is marked with this symbol when it is necessary for the user to refer to the instruction in the documentation. This symbol indicate the presence of a Laser device. This symbol indicates the surface can be hot. Keysight PNA Installation and Quick Start Guide...
- Page 27 The UK conformity mark is a UK government owned mark. Products showing this mark comply with all applicable UK regulations. The Keysight email address is required by EU directives applicable to our product. The CSA mark is a registered trademark of the CSA International.
- Page 28 National legislation. Please refer to https://about.keysight.com/en/companyinfo/environment/takeback.shtml understand your trade-in options with Keysight, in addition to product takeback instructions. China Restricted Substance Product Label. The EPUP (environmental protection use period) number in the center indicates the time period during which no hazardous or toxic substances or elements are expected to leak or deteriorate during normal use and generally reflects the expected useful life of the product.
- Page 29 (European Machinery Directive) Acoustic Noise Emission LpA<70 dB Operator Position Normal Operation mode per ISO 7779 Acoustic Compliance Some models will exceed 55 dB(A) sound pressure at the operator position at high ambient temperatures. Keysight PNA Installation and Quick Start Guide...
- Page 30 This equipment has been conformity assessed for use in business environments. In a residential environment this equipment may cause radio interference. — This EMC statement applies to the equipment only for use in business environment. Keysight PNA Installation and Quick Start Guide...
- Page 31 Environmental Information Samples of this product have been type-tested in accordance with the Keysight Environmental Test Manual and verified to be robust against the environmental stresses of storage, transportation and end-use; those stresses include but are not limited to temperature, humidity, shock, vibration, altitude, and power-line conditions.
- Page 32 The actual warranty on your instrument depends on the date it was ordered as well as whether or not any warranty options were purchased at that time. To determine the exact warranty on your instrument, contact Keysight Technologies with the model and serial number of your instrument. Refer to “Contacting Keysight”...
- Page 33 This information is subject to change without notice. © Keysight Technologies 2009-2025 Edition 1, February 2025 E8356-90001 www.keysight.com...
