Description of the Upgrade
Items Included in the Upgrade Kit
Items Included in the Upgrade Kit
Check the contents of your kit against the following list. If any part is missing
or damaged, contact Keysight Technologies. Refer to
from Keysight" on page
Table 1 Contents of Upgrade Kit N5225-60136
Ref
Desig.
- Installation note (this document)
- Software Entitlement Certificate
- China RoHS Addendum for kits
A10 26.5 GHz source (2) board
A12 40 GHz doubler assembly port 3
A13 40 GHz doubler assembly port 4
A15 Direct digital synthesizer (DDS) assembly, (x4) – (Replaces A11 x2 DDS assembly.)
Splitter
a
A26
A28 Mixer brick (2)
A30 Test port 3 reference coupler
A31 Test port 4 reference coupler
A34 Test port 3 coupler
A35 Test port 4 coupler
- Dress panel, lower 4-port
- Machine screw, M2.0 x 6, flat head (8 to attach two reference couplers to brackets)
Machine screw, M2.5 x 20, pan head (4 to attach A34 and A35 reference coupler
-
assemblies to test set deck)
Machine screw, M4.0 x 10, pan head (2 each to attach the following boards to the
- analyzer chassis: A17 13.5 GHz synthesizer board, A10 26.5 GHz source board, A12
40 GHz doubler assembly port 3, and A13 40 GHz doubler assembly port 4.)
- Machine screw, M3.0 x 6, flat head (to attach front frame to coupler plate)
- Machine screw, M3.0 x 12, pan head (1 to attach cable bracket to test set deck.
- Machine screw, M3.0 x 8, pan head (3 to attach shield to A28 mixer brick)
- Machine screw, M2.5 x 16, pan head (2 to attach splitter to mixer brick)
- Machine screw, M3.0 x 25, pan head (3 to attach A28 mixer brick to block)
- Machine screw, M3.0 x 20, flat head (2 to attach bracket to A10 26.5 GHz source)
12
4.
Description
"Getting Assistance
Qty Part Number
1 N5225-90136
1 5964-5145
1 9320-6722
1 5087-7342
2 5087-7349
1 N5240-60102
1 5067-4086
1 5087-7417
2 5087-7760
2 5087-7793
1 N5240-00009
8 0515-1602
4 0515-0374
7 0515-0380
2 0515-1946
2 0515-0664
4 0515-0372
2 0515-2007
3 0515-0667
2 0515-2078
Installation Note N5225-90136
