tBOX520-ADL-MR Series User's Manual
Step 4 Remove the antenna plug from one antenna hole on the system
chassis, and prepare the antenna cable.
Step 5 Make the antenna cable's gold connector through the antenna hole on
the system chassis and screw it tight with the antenna nut and gasket.
Step 6 Screw the RF antenna to the gold connector.
Step 7 Connect the other end of the cable to the connector on the wireless
module.
12
Hardware Installation
