AXIOMTEK tBOX323-835-FL Quick Installation Manual

Step 3 Slide CFast card into slot cautiously
Step 4 Fasten screws of HDD/CFast bracket

Installing HDMI bracket

Step 1 Fasten the bracket at the position as shown.
Step 2 Connect HDMI cable and tied on bracket by cable tie as
shown.
4 94161N323030E
©
Copyright 2017 Axiomtek Co., Ltd.
Version A4 Feb. 2017
Printed in Taiwan
tBOX323-835-FL Quick Installation Guide

Checklist

tBOX323-835-FL System Unit x 1
Quick Installation Guide x 1
CD x 1 (for Driver & Manual)
Wall mount Bracket x 1
Screws Pack x 1
Foot Pad x4
Key x2
DIO & Serial terminal block
Note: Please contact your local vendors if any damaged or missing items. DO
NOT apply power to the board if there is any damaged component.

Dimensions

9416N323030E
©
Copyright 2017 Axiomtek Co., Ltd.
Version A4 Feb. 2017
Printed in Taiwan
HDD/SSD(Optional)
CFast Card(Optional)
Mini Card Module(Optional)
M12 LAN cable(Optional)
M12 power cable(Optional)
Remote switch cable(Optional)
