Activate Voltage Trigger
Low Voltage Trigger
Shutdown Delay Timer
(Low Voltage)
IGN Trigger
Note: Please refer to APPENDIX B for setting the motion in OS application
AMI BIOS Setup Utility
The system turns on only when the voltage delivered by the
power source is higher than the value you set here.
The system will begin the countdown once voltage drops
below the value you set here.
If the power source voltage does not return to the value
higher than [Activate Voltage Trigger] within the time you set
for [Shutdown Delay Time (Low Voltage)], the system will
shut down and remain off.
The timer will be activated once power source voltage drops
below the value defined in [Low Voltage Trigger]. The system
will be forced to turn off once timer completes countdown.
Enable
[System Turn On Delay] and [Shutdown Delay] will be trigged
by IGN.
Disable
IGN signal will not affect any power management.
tBOX520-ADL-MR Series User's Manual
49
