Installation Instructions - Altronix NetWay5P Series Installation Manual

Altronix Netway5P Series are hardened PoE+ switches. They provide a network data uplink and four (4) PoE ports
to power IP devices, such as PoE access controllers and cameras. Other applications may include solar power
(with NetWay5P and NetWay5PWPN), as well as integrating network door access systems with video surveillance.
For network managed switches see NetWay5PQ Series.
Input:
• 120VAC, 60Hz, 4.5A.
• NetWay5P/NetWay5PWPN:
24VDC from a UL Listed power source or a
solar panel with nominal 24V (~18-35V) output.
Current draw: 6A at maximum 120W output.
Output:
• Four (4) PoE/PoE+ ports.
• IEEE 802.3at (30W) and IEEE 802.3af (15W)
compliant.
• Single data uplink port.
Ethernet Ports:
• Five (5) 10/100/1000 Mbps ports.
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5e or higher structured cable.
• Distance: up to 100m.
• Speed: 10/100/1000 Mbps, half/full duplex,
auto negotiation.
LED Indicators:
• Individual PoE On LEDs for each port.
• Individual IP Link status, 100/1000Base-T/active
LEDs for each port.
Environmental:
• Operating Ambient Temperature:
30ºC to 70ºC (
– –
• Storage Temperature:
40ºC to 85ºC (
– –
• Humidity: 20 to 85%, non-condensing.
• Operating Altitude:
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all local codes
and authorities having jurisdiction. Wiring should be UL Listed and/or Recognized wire suitable for the application.
All units should be installed by a trained service personnel.
Installation:
NetWay5P:
1. Mount NetWay5P in the desired location/enclosure (mounting hardware included).
2. Connect NetWay5P to power source and Ethernet devices:
NetWay5P can be powered by a UL Listed 24VDC power source, e.g. Altronix eFlow power supply/charger
or a solar panel with nominal 24V (~18-35V) output.
3. Connect a power source to the [GND +24V] terminals carefully observing polarity (Fig. 1a, pg. 4).
4. Connect a Data source to the [Data Input] RJ45 jack (Fig. 1b, pg. 4).
5. Connect Access Control boards, Altronix LINQ units or other IP devices to the [Port 1 - Port 4] RJ45 jacks
(Fig. 1c, pg. 4). Refer to the corresponding Installation Guides for details.
- 2 -
22ºF to 158ºF).
40ºF to 185ºF).
304.8 to 2,000m.
–

Installation Instructions:

Overview:
Features:
Applications:
• Allows to power up to four (4) IP devices and
networking of multiple remote devices without the
need for running multiple cables from the main
switch/server.
Mechanical:
NetWay5P:
• Dimensions (L x W x D approx.):
5.9" x 3.6" x 0.75" (150mm x 91.4mm x 19mm).
NetWay5PWPN
• NEMA 4X, IP66 Rated enclosure for outdoor use.
• Dimensions (H x W x D approx.):
9.5" x 7.32" x 4.92"
(241.3mm x 185.9mm x 125mm).
NetWay5PWP:
• NEMA4/4X, IP66 Rated enclosure for outdoor use.
• Dimensions (H x W x D approx.):
13.31" x 11.31" x 5.59"
(338.1mm x 287.3mm x 142mm).
NetWay5PWPX:
• NEMA4/4X, IP66 Rated enclosure for outdoor use.
• Accommodates four (4) 12VDC/4AH batteries
(48V of backup).
• Dimensions (H x W x D approx.):
17.53" x 15.3" x 6.67"
(445.3mm x 388.6mm x 169.4mm).
NetWay5PX:
• Dimensions (H x W x D approx.):
13.5" x 13" x 3.25" (342.9mm x 330.2mm x 83mm).
NetWay5P Series Installation Guide
