4.10 Technical Admin

4.11 Mimic Setup

4.12 Upload Patch

4.13 Data Expire Time

AK-EM 100 Installation Guide
3. This will then add the state to the enumeration. Enter as many states as necessary.
4. Any other enumeration can be modified by altering the text and pressing the 'Save' button.
5. To delete a complete enumeration, press the 'Delete' button on the far right. To delete an
enumeration state, press the 'Delete' button attached to it.

4.9.1 Import/Export Enumerations

You can export and import the Enumeration settings as an XML file. This can be a way of easily
exporting a list from a completed site onto a new similar site without having to manually do it from the
beginning.
1. Press the Go button in the Export/Import section and then right click on the link when it appears
to save it locally.
2. Similarly, browse to the locally stored copy to upload and update the Food Types.
The Technical Information section should only be accessed by experienced personnel or commissioners.
It is where processes can be monitored and started or stopped if absolutely necessary., and also
includes logs of these processes.
Refer to section 3 for more information regarding the set up of the Store Mimic.
If there are any additional upgrades to be added to the AK-EM 100, such as new specifications, they can
be uploaded from here.
1. Press the 'Browse' button to select the patch. The patch must be a compressed tgz file.
2. When selected, press the 'Go' button to install the patch and complete the upgrade.
When live readings are displayed (such as in the Mimics, Basic and Advanced Details, and the Asset
Configuration pages), then it is important to the correct data is displayed at all times.
Readings with '***' will indicate that data isn't available for the point,
that the controller isn't connected, or there is another problem.
This sections allows you to set a timer for live data against a controller,
making sure that the data received is the latest data within the expire
time; the system will check that the data for the asset is fresh within
the set time.
Enter the timeout in the correct format (hh:mm), and press the 'Update' when finished.
© Danfoss 05-2011
RC8BX402 43
