4. Administration Options

4.1 User and Groups

4.2 Reason Administration

Note:
If the application has
been installed from a
new build, and during the
commissioning a Network
Discovery has taken
place, the application will
automatically load up all raw
strings and create Standard
Reasons. (This is for ADAP-
KOOL® only at present).
The Reason Administration
pages will not need to be
accessed except for editing
purposes.
Note:
If an existing system,
where previous Network
Discoveries have been
carried out, the use of
Custom DES Files will
automatically load up
custom alarms, alarm strings,
exceptions and standard
reasons for that asset. (This
is for ADAP-KOOL® only at
present).
AK-EM 100 Installation Guide
The Administration section contains a variety of options for the general set up of the AK-EM 100,
some of which will have more importance than others when setting up the store for the first time by a
Commissioner or Technical Engineer.
Refer to section2.6 for information regarding the set up of new users and groups.
Reason Administration is where the Standard Reasons that appear in the Alarm List can be edited, and
where raw reasons can be mapped against Standard Reason also. The main page displays the standard
reasons their priority (which relates to what level of user has access to levels of alarms) and severity
level (critical or caution alarms) and whether they should be an exception. Click on the 'Edit' button to
change the severity level and edit the name of the reason.
New entries can be entered by filling out the top row of the list and pressing the 'Save' button to add it.
1. Type in a new reason in the first text field. To change a priority for a reason, select a new priority
from the drop down menu. Choose from (in order of highest priority to lowest) Important, Medium,
or Information.
2. To alter the severity of an alarm, select from either critical or caution.
3. Press the 'Save' button at the bottom of the page to store the settings. Any changes will then be
reflected in the Alarm List. Also take into account that changing the priority of an alarm will affect
what alarms certain users will have access to depending on their level of access.
Raw Reasons
To View all of the raw reasons which make up the Standard Reasons, press the 'Raw Reason' radio
button. To change the mapping of a raw reason to different or new Standard Reason, or simply edit a
name, press the 'Edit' button, remembering to save when finished.
© Danfoss 05-2011
RC8BX402 37
