Design and function
Welding task selection
5.4.8

Expert menu (TIG)

The Expert menu has adjustable parameters stored that don't require regular setting. The number of pa-
rameters shown may be limited, e.g. if a function is deactivated.
Display
54
ENTER
4s
EXIT
4s
Setting/selection
Expert menu
Slope time (main current to secondary current)
Slope time (main current to secondary current)
Parameter activArc > see 5.4.7 chapter
Setting the intensity
Filler wire process (cold wire/hot wire)
------- Filler wire disabled (factory setting).
------- Filler wire enabled (additional parameters are indicated).
Hot wire process (start signal for hot wire power source)
------- Function enabled
------- Function disabled (ex works)
Wire/pulse function (wire feeding behaviour when using pulsed TIG welding)
Wire feeding can be disabled during pulse pauses (not the case for automated pul-
sing or kHz pulsing).
------- Function disabled
------- Function enabled (ex works)
Filler wire diameter (manual setting)
Setting the wire diameter between 0.6 mm to 1.6 mm.
The character "d" preceding the wire diameter on the display (d0.8) indicates a pre-
programmed characteristics (correction operating mode "KORREKTUR").
If there is no characteristics for the selected wire diameter, the parameters have to be set
manually (manual operating mode "MANUELL").
Figure 5-41
