Description of the device
4.1
Description
The device is a fresh water make-up station in the facility system. The components below control the make-up process:
•
Pump
–
The pump draws water from public water system via a system separator tank and transports the water into the facility system.
•
Controller
–
The controller regulates and monitors the make-up process.
The device is designed for these facility systems:
•
Heating water systems
•
Cooling water systems
•
Solar circuits
The device is used in combination with a user-supplied open system separator tank.
Note!
An application without system separator tank is possible.
–
For customised design and adjustment, see chapter 12.1 "Reflex Customer Service" on page 47 .
Note!
In a solar circuit, you must have installed a system separator tank to ensure a water/glycol mixture for the circuit.
Note!
It is possible to use the device for the initial filling with fresh water into the facility system.
Fillcontrol Auto — 06.07.2016 - Rev. B
Description of the device
English — 9
