9.3
Messages
Messages with ER codes are displayed at the controller.
•
Use the arrow keys at the controller operating panel to select the messages.
•
By selecting the "Fault memory" main menu in the Customer menu, you display the last 20 alarms.
•
Alarm causes can be eliminated by the operator or a specialist workshop.
•
If required, please contact the Reflex Customer Service.
Note!
Confirm the elimination of the fault by pressing "Quit" at the controller operator panel. All other alarms are automatically
reset as soon as the cause has been eliminated.
Note!
Group messages are issued via floating contacts, settings in the Customer menu, see chapter 7.5 "Parametrising the
controller in the Customer menu" on page 29 .
ER Code
Alarm
01
Min. pressure
–
Only with
Magcontrol
02.1
Insufficient water
04.1
Pump
06
Makeup time
Group
Causes
alarm
YES
The set value for the "P
minimum working pressure
has been exceeded.
•
Water loss in the
system.
•
Expansion tank
defective.
•
Fault at the "PU"
pump.
No water in the system
separator vessel.
•
Ball valve in makeup
line closed.
•
Dirt trap clogged.
•
Float valve defective.
YES
Pump does not start.
•
"PU" pump is stuck.
•
Pump motor defective.
•
10 A fuse defective.
•
Contactor (Klixon)
tripped.
Set time for the makeup
time has been exceeded.
•
Severe water loss in
the system.
•
Makeup line not
connected.
•
Makeup rate
insufficient.
•
Makeup hysteresis too
high.
Fillcontrol Auto — 06.07.2016 - Rev. B
Remedy
"
•
Check the system for leaks.
0
•
Replace the expansion tank.
•
Check the function in manual
mode.
–
"PU" pump
•
Open the ball valve in the
makeup line.
•
Clean the dirt trap.
•
Replace the float valve.
•
Manually turn the pump to
start.
•
Replace the pump motor.
•
Replace the fuse.
•
Check the mechanical and
electrical functions of the
pump motor.
•
Check the system for leaks.
•
Connect the makeup system.
•
Check the makeup rate.
•
Check the makeup hysteresis.
Controller
Alarm reset
"Quit"
"Quit"
"Quit"
English — 39
