Customer menu

The device controller is shipped with the following default settings. Use the Customer menu to adjust these values to local conditions. In
special cases, it is possible to further adjust the values in the Service menu.
Customer menu
Parameter
Language
Fillcontrol XX
Minimum operating pressure p0
Safety valve, pressure
Next maintenance
Floating alarm contact
Makeup
Maximum makeup quantity
Maximum makeup time
Maximum makeup cycles
Softening (Only if "With softening yes")
Lock makeup
Hardness reduction
Maximum makeup quantity
Soft water capacity
Cartridge replacement
9.2.2

Service menu

This menu is protected with a password. It can be accessed only by the Reflex Customer Service. A partial summary of the settings stored
in the Service menu is proved in the Chapter Default settings, see chapter 9.2.2 "Service menu" on page 38 .
Service menu
Parameter
Makeup
Pressure differential, "NSP" makeup
Pressure differential, filling pressure PF – P
Water quantity for each contact
Maximum filling contacts
38 — English
Setting
EN
Magcontrol
1.5 bar
3.0 bar
12 months
NO
5000 Litres
20 minutes
3 cycles within 2 hours
No
8°dH
0 Litres
0 Litres
18 months
Setting
0.2 bar
0.3 bar
0
10 l / K
OFF
