- Page 1 Reflexomat Basic 20.0.9.2020 - Rev. A Reflexomat RS 90 / 1 - adjoining Reflexomat - external air Operating manual Original operating manual...
-
Page 2: Table Of Contents
Installation conditions ................9 12 Disassembly................21 7.1.1 Incoming inspection .............. 9 13 Annex ..................21 Preparatory work ..................9 13.1 Reflex Customer Service ............... 21 Execution ....................9 13.2 Conformity and standards ..............21 7.3.1 Positioning ................9 13.3 Guarantee .................... -
Page 3: Notes On The Operating Manual
Reflex Winkelmann GmbH accepts no liability for any damage resulting from failure to observe the information in this operating manual. In addition to the Personnel requirements... -
Page 4: Description Of The Device
Meaning Control unit Type Device name The control unit comprises a "CO" compressor and the "Reflex Control Basic" controller. Via the primary vessel, the pressure is measured with the "PIS" Serial No. Serial number pressure sensor and the water level with the "LIS" pressure load cell and the min. -
Page 5: Scope Of Delivery
All digital inputs and outputs can be set freely as option. Settings Immediately after receipt of the goods, please check the shipment for to be made by Reflex Customer Service, see chapter 13.1 "Reflex completeness and damage. Please notify us immediately of any transport Customer Service"... -
Page 6: Setting The Analogue Outputs
I/O module (optional expansion module) Device controller with I/O module Device controllers and I/O module in Master-Slave function Control Basic controller in Control Basic controller in Master function Slave function I/O module for the Master I/O module for the Slave function function Master function... -
Page 7: Module Address Setting
• All digital inputs and outputs can be set freely as option. The • Variable setting to ON or OFF setting is carried out by Reflex Customer Service, see chapter 13.1 DIP switch 5: • Permanently to position ON "Reflex Customer Service" on page 21 DIP switch 6 –... -
Page 8: Replacing The Fuses
Technical data Location Signal Message text Fault memory Priority Signal on the input triggers the following action evaluation entry Changeover Make-up fault • Make-up setting values exceeded. contact • Switches the following messages in the device controller: • "ER 06", Make-up time •... -
Page 9: Installation Conditions
Confirm that installation and start-up have been carried out correctly using the installation and commissioning certificate. This action is a prerequisite for the making of warranty claims. – Have the Reflex Customer Service carry out commissioning and the annual maintenance. Installation conditions 7.1.1 Incoming inspection Prior to shipping, this device was carefully inspected and packed. -
Page 10: Connection To The Facility System
For details regarding the switching of Reflexomats or in-line vessels and ATTENTION the dimensions of the expansion lines, please see the planning documents. More information is also provided in the Reflex Planning Damage to cables and pipes Guide. If cables and pipes are not routed professionally between tanks and the control unit, they may become damaged. -
Page 11: Connection To An External Compressed Air Line
See chapter "Terminal plan" for the solenoid valve electrical connection. Preferably, you should use the Reflex Fillset with integrated system separator when using drinking water for make-up. If you don't use a Reflex Fillset, you 7.3.5 Fitting the level sensor must use an "ST"... -
Page 12: Electrical Connection
RS-485 interface Reflex Fillset Impulse Expansion pipe Shielding Digital inputs The Reflex Servitec degassing and make-up station degasses the water from the • Water meter facility system and the make-up water. The automatic water make-up for the • Insufficient water facility system is controlled by the pressurisation system. -
Page 13: Rs-485 Interface
All messages, see chapter 10.2.2 "Messages" on page 17 . – All entries in the fault memory. Note! If required, please contact the Reflex Customer Service for the protocol of the RS-485 interface, details of the connections and information about the accessories offered. 7.5.2.1 Connecting the RS-485 interface •... -
Page 14: Modifying The Controller's Start Routine
The "Auto" LED at the operator panel illuminates to visually signal controller" on page 15 . automatic mode. – Contact Reflex Customer Service, see chapter 13.1 "Reflex Customer Service" on Note! page 21 . Initial commissioning is completed and the device is in continuous •... -
Page 15: Operation
Operation Operation Note! The system returns an alarm if the Stop mode is activated for more than Operating modes 4 hours. If "Floating alarm contact?" in the Customer menu is set to "Yes", the 9.1.1 Automatic mode system outputs the alarm to the group alarm contact. Use: After initial commissioning has been successfully completed Controller... - Page 16 • YES: The system stops the make-up process when balancing is still not possible, cancel with "Yes". the set soft water capacity is exceeded. Contact your Reflex Customer Service. • NEIN: The system does not stop the make-up • NO: Check the prerequisites for the commissioning, process.
-
Page 17: Default Settings
Only if make-up has been Alarm causes can be eliminated by the operator or a specialist workshop. If this is volume selected in the customer menu not possible, contact the Reflex Customer Service. with "With water meter Yes". Note! - Page 18 Replace the softening cartridges. "Quit" • Time interval for replacement of the softening cartridge exceeded. I/O module fault • I/O module defective. Inform Reflex Customer Service. • Connection between option card and controller faulty. • Option card defective. EEPROM defective •...
-
Page 19: Maintenance
Checking Insufficient water "Off" Arrange for maintenance tasks must be carried out only by specialist 14. Check the displayed value for the Insufficient water "OFF" filling level personnel or Reflex Customer Service. message. – Insufficient water "Off" is displayed at the controller at a minimum 11.1... -
Page 20: Cleaning
Note! water or condensate, you must check the diaphragm for rupture. Clean all other installed dirt traps (in the Reflex Fillset, for example). • The vessel must be replaced if the diaphragm has ruptured. Close the "PV" overflow solenoid valve if the display indicates a 100% level. -
Page 21: Disassembly
Conformity and standards • Wait until hot surfaces have cooled down or wear protective safety gloves. Device conformity declarations are available on the Reflex homepage. • The operating authority is required to place appropriate warning signs www.reflex-winkelmann.com/konformitaetserklaerungen in the vicinity of the device. - Page 22 Annex Installation and commissioning certificate - This device has been installed and commissioned in accordance with the instructions provided in the operating manual. The settings in the controller match the local conditions. Typ / Type: Fabr. Nr. / Serial-No. 22 — English Reflexomat Basic —...
