Summary of Contents for Reflex Servitec 35

  • Page 1 18.12.2019 - Rev. A Servitec 35-95 with Touch controller Vacuum spray degassing Operating manual Original operating manual...
  • Page 2: Table Of Contents

    Commissioning ..............12 Checking the requirements for commissioning ....12 Servitec 35-95 with Touch controller 18.12.2019 - Rev. A Setting the minimum operating pressure for Magcontrol . 13 2 — English Servitec 35-95 with Touch controller — 18.12.2019 - Rev. A...
  • Page 3: Notes On The Operating Manual

     Note! Reflex Winkelmann GmbH accepts no liability for any damage resulting from This symbol, in combination with the signal word 'Note', indicates failure to observe the information in this operating manual. In addition to the useful tips and recommendations for efficient handling of the product.
  • Page 4: Residual Risks

    Reduction of corrosion damage by removal of oxygen from the Servitec 75 – 95 water.  Note! The device can only be operated at water temperatures up to a maximum of 90 °C. 4 — English Servitec 35-95 with Touch controller — 18.12.2019 - Rev. A...
  • Page 5: Nameplate

    The pump returns degassed water from the vacuum spray tube to the system where it again begins to dissolve gases. There it is able to dissolve gases again. Servitec 35-95 with Touch controller — 18.12.2019 - Rev. A English — 5...
  • Page 6: Scope Of Delivery

    1150 Internal thread ½ " Internal thread 1 " 1150 Internal thread ½ " Internal thread 1 " 1150 Internal thread ½ " Internal thread 1 " 6 — English Servitec 35-95 with Touch controller — 18.12.2019 - Rev. A...
  • Page 7: Operation

    The device is pre-wired and must be adapted for the local system conditions. Complete the water-side connection to the system and the electric connection as shown in the terminal diagram, see chapter 6.5 "Electrical connection" on page 10. Servitec 35-95 with Touch controller — 18.12.2019 - Rev. A English — 7...
  • Page 8: Fitting The Add-On Components

    "DC" degassing line (degassed water) "DC" degassing lines (gas-rich water) "WC" make-up line Optional equipment and accessories see chapter 4.6 "Optional equipment and accessories" on page 6 . Servitec Expansion vessel 8 — English Servitec 35-95 with Touch controller — 18.12.2019 - Rev. A...
  • Page 9: Switching And Make-Up Variants

    In this manner the permissible temperature range of 0° - 90°C is adhered to. 6.4.2 Level dependent "Levelcontrol" make-up mode Typical representation of Servitec 35 - 95 with motorized ball valves in a facility system. Servitec "BT" system separator vessel "WV"...
  • Page 10: Electrical Connection

    5 "Technical data" on page 6 . Install the cover. Connect the mains plug to the 230 V power supply. Activate the system. The electrical connection is completed. 10 — English Servitec 35-95 with Touch controller — 18.12.2019 - Rev. A...
  • Page 11: Terminal Plan, Connection Component

    For regulating the WV make-up valve Pre-wired Pre-wired 0–10V (correcting hydraulic adjustment variable) (white) of degassing. 0–10V (feedback) (orange) CD degassing control valve Pre-wired "PU" pump Pre-wired Servitec 35-95 with Touch controller — 18.12.2019 - Rev. A English — 11...
  • Page 12: Terminal Plan, Operating Unit

    All entries in the fault memory. The following accessories are available for interface communication. – Bus modules • Profibus-DP. • Ethernet. • Optional I/O module. • Modbus RTU. 12 — English Servitec 35-95 with Touch controller — 18.12.2019 - Rev. A...
  • Page 13: Setting The Minimum Operating Pressure For Magcontrol

    The calculation of the minimum operating pressure can be directly calculated • Opens help texts. • Displays general and saved during initial commissioning using the Reflex Control Smart app for information. configuration. Please always check the correct inlet pressure of the expansion vessel in the system. Proceed as follows: 7.3.2 Calibrating the touch screen In the app, set the controller to "Magcontrol".
  • Page 14: Modifying The Controller's Start Routine

    Use the "Up" and "Down" buttons to change the display value. – Confirm your entries with "OK". Confirm your entries via the "OK" button. – The start routine moves to the next page. 14 — English Servitec 35-95 with Touch controller — 18.12.2019 - Rev. A...
  • Page 15: Filling The Device With Water And Venting

    Note the vacuum indicated on the vacuum gauge. – Air escapes via the degassing valve (2) and the water pressure can be read at the vacuum gauge (1). Servitec 35-95 with Touch controller — 18.12.2019 - Rev. A English — 15...
  • Page 16: Use The Device To Fill The Facility System With Water

    Note! Fault messages, see chapter 9.2 "Messages" on page 20  Note! Filling the system with water is not part of the deliverables of the Reflex Customer Service. To start the Automatic mode, proceed as follows: • Touch the "AUTO" button.
  • Page 17: Manual Mode

     Note! In device automatic mode, jamming of the pump is prevented by a forced start (after 24 hours). Servitec 35-95 with Touch controller — 18.12.2019 - Rev. A English — 17...
  • Page 18: Controller

    • Fillsoft II + softening: Soft water capacity = 12000 l / hardness reduction. • Fillsoft II desalination: Soft water capacity = 6000 l / hardness reduction. 18 — English Servitec 35-95 with Touch controller — 18.12.2019 - Rev. A...
  • Page 19: Service Menu

    Only Magcontrol 9.1.2 Service menu Degassing This menu is protected with a password. It can be accessed only by the Reflex Customer Service. A partial summary of the settings stored in the Service menu is Idling times between 10 hours Idling times between the proved in the Chapter Default settings, see chapter 9.1.3 "Default settings"...
  • Page 20: Setting Degassing Programmes

    If necessary, you can set the output of messages via a floating contact in the Customer menu. Press "(012) Degassing programme". – The controller opens the list of degassing programmes. 20 — English Servitec 35-95 with Touch controller — 18.12.2019 - Rev. A...
  • Page 21 Power failure No power. Connect to power supply. – Stop ˃ 4 hours Longer than 4 hours in stop mode. Set the controller to Automatic mode. – Servitec 35-95 with Touch controller — 18.12.2019 - Rev. A English — 21...
  • Page 22: Maintenance

    The ’Servitec’ must be serviced annually or after 16,000 degassing intervals, The annual maintenance is displayed upon expiry of the set operating whichever comes first. time. • Press "OK" to acknowledge the "Service recommended" message. 22 — English Servitec 35-95 with Touch controller — 18.12.2019 - Rev. A...
  • Page 23: Exterior Leak Test

    Maintenance certificate If installation, removal or maintenance work is not carried out correctly, there is a All maintenance tasks have been completed according to the Reflex Installation, risk of burns and other injuries at the connection points, if pressurised hot water Operating and Maintenance Manual.
  • Page 24: Inspection

    Hot surfaces in heating systems can cause burns to the skin. • Wear protective gloves. • Please place appropriate warning signs in the vicinity of the device. 24 — English Servitec 35-95 with Touch controller — 18.12.2019 - Rev. A...
  • Page 26 Reflex Winkelmann GmbH Gersteinstraße 19 59227 Ahlen, Germany +49 (0)2382 7069-0 +49 (0)2382 7069-9546 www.reflex.de...
