8.
Press "OK" and switch into the "Make-up" main menu.
Use the "▼▲" arrow keys to navigate and set the values in the selected main
menu.
9.
Use the "▼▲" arrow keys to open the "Make-up" sub-menu.
Press "Quit" to return to the previous main menu option.
10. Press "OK" and change the time for a make-up cycle, if required.
Upon expiry of the set time, the system interrupts the make-up and returns the
"Make-up time" fault message.
11. Press "OK" and change the number of make-up cycles, if required.
If the set number of make-up cycles is exceeded within 2 hours, the system
interrupts the make-up and returns the "Make-up cycles" fault message.
12. Press "OK" and select a setting for "With water meter":
Yes: FQIRA+ contact water meter is installed, see chapter 4.6 "Optional
equipment and accessories" on page 13 . This is the prerequisite for the make-up
quantity monitoring and the operation of a softening system.
NO: A contact water meter is not installed (standard model).
The following sub-menus are only displayed if "YES" has been set in the "With water meter"
menu option.
13. Press "OK" to select "Make-up quantity".
Press "YES" to reset the value displayed to "0".
Press "No" to retain the displayed value.
14. Press "OK" to select "maximum make-up quantity" and change the quantity, if required.
When the set quantity is reached, the system interrupts the make-up process and
returns the error message "Max. make-up quantity exceeded".
15. Press "OK" and change the setting for "With softening", if required.
YES: The system offers more queries regarding the softening process.
NO: The system does not offer more queries regarding the softening process.
Fillcontrol Auto — 06.07.2016 - Rev. B
Make-up >
▼Make-up
Max. make-up time
020 min.
(023)
Max. make-up cycl.
003 / 2 h
(024)
With water meter
YES
Make-up quantity
000020 l
Max. make-up qty.
100 l
With softening
YES
English — 35
Controller
(027)
(028)
(029)
(030)
