Commissioning
7.7

Use the device to fill the facility system with water

You have the option to use the device to fill the facility system with water. These requirements must be met for the filling with water:
• The facility system has not been previously filled with water.
• The facility system has a maximum water volume up to 3,000 litres.
• It is a facility system with a diaphragm expansion system.
Set the following operating modes at the controller:
• "Magcontrol" make-up, see chapter 9.2.1 "Customer menu" on page 38 .
• Manual operation, see chapter 8.1.2 "Manual mode" on page 31 .
Proceed as follows:
1. Press "Manual" on the controller's operator panel.
2. Use the arrow keys at the operator panel to select "Fill" on the display. – "Fill" flashes
at the display as a visual signal of the selection.
3. Press "OK" on the controller's operator panel.
– The pump is switched on and the displays shows "Fill!".
– The controller calculates the required filling pressure. As soon as this value has
been attained, the controller automatically stops the filling process.
The facility system is filled with water.
Note!
Monitor the system for the entire automatic filling process.
Note!
If the maximum filling time (10 hours by default) is exceeded, the system aborts the make-up process with an error
message.
– After the cause has been found, acknowledge the error message by pressing "Quit" at the controller's operating
panel and continue with the filling process, see chapter 9.3 "Messages" on page 39 .
7.8

Starting Automatic mode

Automatic operation can be started after initial commissioning. The following prerequisites must be met for automatic operation:
" minimum working pressure is entered in the controller.
• "P
0
• The device is filled with water.
• All required parameters are defined in the controller.
• The function test has been concluded.
Start the automatic mode at the operator panel of the controller:
• Press "Auto" for automatic operation.
• The "Auto" LED at the operator panel illuminates to visually signal automatic operation.
Note!
The commissioning process is now concluded.
30 — English Fillcontrol Auto — 06.07.2016 - Rev. B
10 h 2.0 bar
PU! Fill!
