7.5

Parametrising the controller in the Customer menu

Use the Customer menu to display or correct system-specific values. In the course of commissioning, the factory settings must be
adjusted for the system-specific conditions.
– For adjusting the default settings, see chapter 9.2 "Configuring settings in the controller" on page 34 .
– For information about controller operation, see chapter 9.1 "Operator panel" on page 33 .
7.6

Function test

At the device, execute a function test for the "PU" pump.
– Set the controller to manual mode, see chapter 8.1.2 "Manual mode" on page 31 . In manual mode, you manually activate and
deactivate the "PU" pump.
Select the "PU" pump. Selecting the pump depends on the set make-up variant,
"Levelcontrol" or "Magcontrol".
Proceed as follows:
1. Press "Manual" on the controller's operator panel.
– "PU" flashes at the display as a visual signal that the pump has been selected for
the "Levelcontrol' make-up variant.
– Use the arrow keys at the operator panel to select "PU" on the display. –
"PU" flashes at the display as a visual signal that the pump has been selected for
the "Magcontrol' make-up variant.
2. Press "OK" on the controller's operator panel.
– The pump is switched on and the displays shows "PU!".
– The display must show values of ≥ 5 bar for the pressure when the pump is
switched on.
3. Press "OK" on the controller's operator panel.
– The pump is switched off and the displays shows "PU".
The function test for the pump is completed. Slowly open the "BV" shut-off valve in the
pressure line from the pump to the facility system.
Note!
If the pressure does not rise when the pump is activated:
• Shut down the pump
• Vent the pump, see chapter 7.3 "Filling the device with water" on page 27 .
Note!
Execute a function test of the system separator tank according to the user-supplied specifications.
Fillcontrol Auto — 06.07.2016 - Rev. B
Commissioning
2.0 bar
PU! Filling
English — 29
