Configuring settings in the controller

Use the Customer menu to display or correct system-specific values. In the course of commissioning, the factory settings must be
adjusted for the system-specific conditions.
Proceed as follows:
1. Press "Manual" to switch to manual operation.
2. Press "Menu" to display the first main menu option "Customer menu".
You are in the "Customer menu" main menu.
To navigate and set the values:
– Use the "▼▲" arrow keys to navigate and set the values in the selected main menu.
– Press "OK" to open the next sub-menu.
– Press "OK" to confirm the changed setting in the sub-menu.
Note!
For a description of the operation, see chapter 9.1 "Operator panel" on page 33 .
You are in the "Customer menu" main menu.
1. Use the "▼▲" arrow keys to open the "Language" sub-menu.
2. Press "OK" and change the desired language.
3. Press "OK" and change the displayed "Hour", "Minute" and "Second". The active value
to be changed flashes.
– This time is used for entries in the fault memory.
4. Press "OK" and change the displayed "Day", "Month" and "Year". The active value to be
changed flashes.
– This date is used for entries in the fault memory.
5. Press "OK" and select the required make-up variant, "Levelcontrol" or "Magcontrol".
The system displays the "Minimum working pressure" message when you have set the
"Magcontrol" make-up variant.
6. Press "OK" and enter the minimum working pressure.
The system displays the "Safety valve pressure" message when you have set the
"Magcontrol" make-up variant.
7. Press "OK" and enter the actuating pressure for the safety valve.
– Refer to the facility system for specifying the actuating pressure of the safety
valve.
34 — English Fillcontrol Auto — 06.07.2016 - Rev. B
▼Customer menu
Language
Time:
Date:
Fillcontrol +
Magcontrol
Min. op. pressure
01.8 bar (005)
Safety valve pressure
03.0 bar (006)
