Controller
The following sub-menus are only displayed if "YES" has been set in the "With softening"
menu option.
16. Press "OK" and change the setting for "Lock make-up", if required.
– YES: The system stops the make-up process when the set soft water capacity is
exceeded.
– NO: The system does not stop the make-up process. The system displays the
"Softening" message.
17. Press "OK" and enter the value for hardness reduction.
• Hardness reduction is calculated from the difference of the overall water hardness
GH and the target water hardness GH
actual
Hardness reduction = GH
– Consult the manufacturer information for the values of third-party products.
18. Press "OK" and enter the value for attainable soft water capacity.
– The attainable soft water capacity is calculated from the type of softening used
and the specified hardness reduction.
– Fillsoft I, soft water capacity ≤ 6000/hardness red. l
– Fillsoft II, soft water capacity ≤ 12000/hardness red. l
– Consult the manufacturer information for the values of third-party products.
The value of the remaining soft water capacity is only displayed. It cannot be set and is
calculated from the hardness reduction and the soft water capacity.
19. Press the "▼▲" arrow keys to switch into the next menu option.
20. Press "OK" and enter the time for replacing the softening cartridge.
– Enter the time interval specified by the manufacturer. The system displays the
"Softening" message when this interval has expired.
– The time interval for cartridge replacement is independent od the calculated soft
water capacity.
21. Press "OK" and select a setting for "Next maintenance":
– OFF: Without maintenance recommendation.
– 001 – 060: Maintenance recommendation in months.
22. Press "OK" and select a setting for "Floating fault contact":
– YES: For the output of all messages to the floating contact.
NO: Output of all messages identified with "xxx" ("01", for example).
–
36 — English
.
target
-GH l °dH.
actual target
Fillcontrol Auto — 06.07.2016 - Rev. B
Lock make-up?
YES
Hardness reduction
10 °dH
Cap. soft water
00600 l
Remaining cap. soft w.
000020 l
Replacement in
18 months
Next maintenance
012 months
Floating fault contact
YES
(031)
(033)
(032)
(035)
(034)
