Ordering Information; Bill Of Materials - Analog Devices ADP5091-2-EVALZ User Manual

UG-927

ORDERING INFORMATION

BILL OF MATERIALS

Table 3. Bill of Materials of Evaluation Board
Qty Reference Designator
1 B1
2 C1, C4
2 C2, C5
1 C3
1 C6
1 C7
1 J1
1 J2
1 J3
1 J4
1 L1
1 R1
1 R2
1 R3
2 R4, R19
2 R5, R6
2 R7, R10
1 R8
1 R9
2 R11, R14
1 R12
1 R13
1 R15
4 R16, R17, R20, R21
1 R18
1 R22
3 R23, R24, R25
1 TP1
1 TP2
1 TP3
1 TP4
2 TP5, TP6
1 U1
Table 4. Bill of Materials of PV Board
Qty Reference Designator
1 J1
1 J2
1 J3
Description
CR2032 holder
0.1 μF capacitors, C0603
4.7 μF, 10 V capacitors, C0603
Supercapacitor, 12 × 12
10 nF capacitor, C0603
10 μF, 10 V capacitors, C0603
DIS_SW jumper, SIP2
V and REG_OUT setting jumper,
OUT
SIP10_dual
Input jumper, SIP10_BtoB
Output jumper, SIP8_2rows
22 μH inductor, 3 × 3
442 kΩ resistor, R0603
221 kΩ resistor, R0603
56 kΩ resistor, R0603
5.9 MΩ resistor, R0603
3.3 MΩ resistor, R0603
4.22 MΩ resistors, R0603
4.7 Ω resistor, R0805
3.3 kΩ resistor, R0603
6.65 MΩ resistor, R0603
100 kΩ resistor, R0603
150 kΩ resistor, R0603
4.7 MΩ resistor, R0603
No connect (NC) resistors, R0603
18 MΩ resistor, R0603
1 MΩ resistor, R0603
0 Ω resistor, R0603
PGOOD test point, SIP1
BAT test point, SIP1
BATT test point, SIP1
VOUT test points, SIP1
GND test points, SIP1
ADP5091 24-lead LFCSP
Description
Output jumper, SIP10
Input 1 jumper, PV_INPUT
Input 2 jumper, PV_INPUT
Part Number
BC2032-F1
GRM188R71H104KA93
GRM21BR61A475KA73
PB-5R0H104-R
GRM188R71H103KA01
GRM188R61A106KE69D
61304011121
61031021121
61301011021
9-103324-0
EPL3015-223ML, 744025220
CRCW0603442KFKEA
CRCW0603221KFKEA
CRCW060356K0FKEA
CRCW06035M90FKEA
CRCW06033M30FKEA
CRCW06034M22FKEA
CRCW08054R70JNEAIF
CRCW06033K30FKEA
CRCW06036M65FKEA
CRCW0603100KFKEA
CRCW0603150KFKEA
CRCW06034M70FKEA
Not applicable
CRCW060318M0JPEAHR
CRCW06031M00FKEA
CRCW06030000Z0EA
61304011121
61304011121
61304011121
61304011121
61304011121
ADP5091ACPZ-1-R7
Part Number
613010143121
Not applicable
Not Applicable
Rev. 0 | Page 8 of 9
ADP5091-2-EVALZ User Guide
Vendor
Memory Protection Devices
Murata
Murata
Cooper Bussmann
Murata
Murata
Würth Elektronik
Würth Elektronik
Würth Elektronik
TE Connectivity
Coilcraft, Würth Elektronik
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Not applicable
Vishay Dale
Vishay Dale
Vishay Dale
Würth Elektronik
Würth Elektronik
Würth Elektronik
Würth Elektronik
Würth Elektronik
Analog Devices
Vendor
Würth Elektronik
Alta Device
Alta Device
