Evaluation Board User Guide
32 2 R7, R8
33 1 R76
34 2 REFIO, TMP
35 4 REF_IO, SDN_IO_1,
SDN_RESET, VREF_5V
36 4 S1, S2, S3, S4
37 1 SYNC_IN
38 2 TP2, TP3
39 1 U2
40 1 U3
41 1 U4
42 1 U5
43 1 U6
44 1 U7
45 1 U8
analog.com
100 kΩ, 5%, 1/10 W,
0402, AEC-Q200
Resistors, surface-
mount device (SMD), 50
Ω, 1%, 1/10 W, 0603
AEC-Q200
Resistor, surface-mount
device (SMD), 1 MΩ,
1%, 1/10 W, 0402,
AEC-Q200
Connector-PCB, test
point violet
Connector-PCB, 3
position header
Switch, surface mount,
mechanical
Connector-PCB, SMB
connector plug, 50 Ω,
through hole solder
Connector-PCB, test
point purple
IC, dual Buffer with 3-
state outputs
IC, 32 kb serial
electrically erasable
programmable read-
only memory
(EEPROM)
IC, low power, low noise
V with sink/source
REF
capability
IC-ADI, rail-to-rail, fast,
low power transistor-
transistor
(TTL)/componentized
metal-oxide
semiconductor (CMOS)
components
IC-ADI, 1.2 V ultralow
power high power
supply rejection ratio
(PSRR) voltage
reference
IC-ADI 8 MHz rail-to-rail
operational amplifier
IC 2 kb soft error rate
(SER) I 2 C bus,
Vishay, CRCW060350R0FKEA
Panasonic, ERJ-2RKF1004X
Components Corporation, TP104-01-07
Samtec, TSW-103-08-G-S
Omron, B3S1000
Amphenol, 142134
Keystone, 5124
On Semiconductor, NL27WZ125USG
Microchip Technology, 24LC32A/SN
Analog Devices, ADR365BUJZ
Analog Devices, ADCMP608BKSZ
Analog Devices, ADR280AKSZ-REEL7
Analog Devices, AD8519ARTZ
STMicroelectronics, M24C02-RMN6TP
AD8460
