Product description

3.1

Device description

Device size XS GN
The connections for the installation are located on the rear side of the device:
6
1 Equipotential bonding (Earth
Ground)
3 Electrical connection
5 Safety overflow for wastewater
connection
Device size 6 half size to 10 full size GN
The connections for the installation are located on the rear side of the device:
8
7
6
1 Network connection
3 Power supply
5 Optional connection
7 Safety overflow for wastewater
connection
80.06.083_iCombiPro-iCombiClassic_IM_en-US
5 4 3 2
2 Water connection
4 Waste water connection
6 Network connection
2 Only for gas devices: Gas connec-
tion
Only for electrical devices: Electri-
cal connection
4 Water connection
6 Wastewater connection
8 Equipotential bonding (Earth
Ground)
3 | Product description
1
1
2
3
4
5
