Configuring the Courier V.Everything Modem for Leased Line Operation

You can use the Courier V.Everything modem in either smart or dumb
mode (determined by the position of DIP switch 8).
If you are using your modem on a leased or dedicated line, it is set to
&L1, and the remote modem has a comparable setting, the modems
automatically connect when they are powered on. They also reconnect,
without any operator intervention, if a disturbance on the line is severe
enough to break the connection.
1 Set your terminal or communications software to the rate at which you
want the modems to communicate.
For example, use a terminal/software setting of 9600 bps and, if both
modems have the capability, they will connect at 9600 bps.
2 Send
AT&B1&S2&H1&L1&W
.
&B1 Fixes the Courier V.Everything modem's serial port
rate at the same rate you selected when setting up
your communications software.
&S2 Causes the Courier V.Everything modem to send a
Clear to Send (CTS) signal only after it sends the
Carrier Detect (CD) signal, that is, only after it
connects with the remote modem.
&H1 Enables hardware (CTS) flow control.
&L1 Forces the modems off hook at power on and
enables them to re-establish the connection should
it be broken (for leased lines only).
&W Writes the settings to nonvolatile memory
(NVRAM) as power-on defaults.
We recommend using the &S2 setting to delay CTS until after the
connection is made, as a precaution.
If the modems are in the process of connecting or reconnecting, the
Courier V.Everything modem interprets any keyboard data entry,
including an accidental key stroke, as a key-press abort, and hangs up.
Delaying CTS until after carrier detection prevents this from happening.
However, you have to set the Courier V.Everything modem for hardware
flow control by sending
If your software or machine does not support Clear to Send (CTS), don't
include &S2 and &H1 in the command string as suggested above. But
keep in mind that if the modems fail to connect or reconnect, the reason
could be a keypress abort.
to the modem
.
AT&H1
16-3
