Intesis DALI-2 Protocol Translator with Serial and IP Support - 1 DALI
Channel
Register name
Control Gear Failure
Light Source Start Counter Resettable
Light Source Set Start Counter Resettable
Light Source Start Counter
Light Source On Time Resettable
Light Source Set On Time Resettable
Light Source On Time
Light Source Temperature
Optional signal
Lamp Failure
Rated Median Useful Life Of Luminaire
Optional signal
Internal Control Gear Reference
Temperature
Optional signal
Rated Median Useful Light Source Starts
Optional signal
Address formula:
y: Channel number (0)
xx: Ballast short address (0 .. 63)
Table 25. Area
Register name Possible values
0: Vacant
1: Occupied
Ay-x Occupancy State
2: Transition
3: Unkown
Ay-x Light Average Average readings of the sensors in the area
0: Inactive
Ay-x Daylight Scene Active
1: Active
Address formula:
y: Line number (0)
x: Area index (0 .. 16)
Page 38 of 40
Possible values
bitfields
0: Overal failure
1: Ext. Supply Undervoltage
2: Ext. Supply Overvoltage 25000+(3200*y)+(100*xx)+51
3: ECG Output Power Limit
4: Thermal derating
5: Thermal shutdown
0 .. 16777213 25000+(3200*y)+(100*xx)+52
0 .. 16777213 25000+(3200*y)+(100*xx)+54
0 .. 16777213 25000+(3200*y)+(100*xx)+56
0 .. 16777213 seconds 25000+(3200*y)+(100*xx)+58
0 .. 4294967293 seconds 25000+(3200*y)+(100*xx)+60
0 .. 4294967293 seconds 25000+(3200*y)+(100*xx)+62
-60 .. 193°C 25000+(3200*y)+(100*xx)+64
bitfields
0: Overal failure
1: Open Circuit
25000+(3200*y)+(100*xx)+65
2: Short Circuit
3: Thermal Derating
4: Thermal Shutdown
0 .. 253 (x1000 hours) 25000+(3200*y)+(100*xx)+66
-60 .. 193°C 25000+(3200*y)+(100*xx)+67
0 .. 65534 (x100 times) 25000+(3200*y)+(100*xx)+68
7000*y+6840+(9*x)+0
7000*y+6840+(9*x)+1
7000*y+6840+(9*x)+2
DALI to Modbus TCP and RTU
Address formula R/W
R
R
RW
R
R
RW
R
R
R
R
R
R
Address formula R/W
R
R
R
USER MANUAL Version 1.0.2
